| Models and Sizes | Berkeley | Crompton | ||||
|---|---|---|---|---|---|---|
| RSB140 | RSB200 | RSB270 | RSB355 | RMB140 | RMB270 | |
| Pillar Size (mm) | ||||||
| Height | 1000 | 1450 | 1000 | 1000 | 1000 | 1000 |
| Diameter | 140 | 270 | 270 | 355 | 140 | 270 |
| Root | 300 | 300 | 300 | 300 | 300 | 300 |
| Finish | ||||||
| Material | 2.5mm Stainless Steel | 3mm Mild Steel | ||||
| Finish | Satin Polish | Hot Dipped Galvanised | ||||
| Backboard (mm) | ||||||
| Height | 500 | 750 | 600 | 600 | 500 | 600 |
| Width | 100 | 200 | 200 | 270 | 100 | 200 |
Standard features include-
- Fitted with Triangular Head Locks
- Backboard of 18mm plywood, treated with clear water repellent
- Earthing point fitted to both pillar and door
Options include-
- Pre-wired panels
- Alternative locks
- Painted to customer spec
- Manufactured in Aluminium
